Gain Diagram
D121014H11 S1.7P-N WG
Features & Benefits
D121014H11 S1.7P-N FB
Specifications
D121014H11 S1.7P-N WI
In-Building DAS
D121014H11
Low PIM SISO Omni / 698-960, 1710-2700 MHz / 2, 5 dBi / 360°
Electrical Specification
Frequency range (MHz) 698-960 1710-2500 2501-2700
Polarization Vertical
Gain (dBi, Typical) 2 5 5
Horizontal BW (°) 360
Vertical BW (°) 80 65 65
Impedance (Ω) 50
VSWR < 1.7:1 < 1.8:1 < 2.0:1
Intermodulation IM3 (dBc) < -153 (2x43dBm)
Max. Effective Power per Port (watts) 50
Mechanical Specification
Connector Type & Quantity N type-Female
Antenna Dimension (H x W x D) Ø202.5 x 102.1 mm | Ø7.97 x 4.02 in
Weight 0.52 kg | 1.14 lb
Mounting Thru-hole ceiling mount Cable Length 452.12mm (17.8”)
Radome (Color) PC, UL94V-0 UV resistant
PIM Test
